Stainless steel forged threaded forged socket elbow
Description
Forged threaded elbow is mainly a high-pressure elbow pipe connection fitting which is formed from round steel or steel ingot by die-pressing and forging the blank, and then processed and formed by a lathe. It is a kind of forged socket series pipe fittings.
Forged threaded elbow (also known as thread elbow) is a pipe fitting used in piping systems to change the direction of the pipe fitting.According to the form, it is divided into 45° socket elbow and 90° socket elbow. In addition, it also includes other abnormal angle elbows such as 60° according to engineering needs.
According to common standards, the specifications of socket elbows are DN6, DN8, DN10, DN15, DN20, DN25, DN32, DN40, DN50, DN65, DN80, DN100. The commonly used order specification is DN15----DN50. If the specifications are beyond the scope, we can communicate with customers on the design and processing of drawings.
Usually made of materials, common raw materials for socket pipe fittings are generally divided into carbon steel, stainless steel, alloy steel, etc.
Product Type: Threaded forged pipe fittings, socket forged pipe fittings
Common manufacturing materials:Commonly used raw materials generally divided into carbon steel, stainless steel, alloy steel, etc.
Stainless steel forged union
Manufacturing Standard: National Standard: GB/T14626,GB/T12459, GB/T13401, HG/T21635, HG/T21631
American Standard: ASME/ANSI B16.11 B16.9 MSS SP43 MSS SP97
Japanese standard: JIS B 2311/2220
German standard: DIN2605/2616/2615/2617
Russian standard: GOST 17375/17376 and so on
Non-standard customized processing drawings are also acceptable
Material: stainless steel OCr18Ni9,0Cr18Ni9Ti,1Cr18Ni9Ti；304,304L,316,316L,316Ti,317,317L,321,321H,310,310S；1.4301,1.4306,1.4401,1.4435,1.4571,1.4436,1.4438,1.4541；08X18H10(0X18H10), 03X18H11(000X18H11),03X17H14M2 (000X17H13M2) ；08X18H10T(0X18H10T)
